Edge curved machine - Sigma
| Edge curved machine - Sigma | |
|---|---|
|
|
|
|
Brand |
Sigma |
|
Industry |
China |
|
Model |
KN-700-3 |
|
Dimensions |
2040 mm × 1500 mm × 1660 mm |
|
Weight (approx.) |
~ 530 kg |
|
Air pressure |
6 – 8 MPA |
|
Types of boards |
MDF/HDF/particle board/multilayer board/malacca board |
|
Glue |
– Types of glue: EVA – Glue pot capacity: 2.6L – Temp of glue:110°c – 210°c |
|
Strip |
– Material: PVC/ Wood verneer/melamine/plastic – Width strip: 14 – 70 mm – Thickness strip: 0.5 – 3 |
|
Banding speed |
0 – 37 mm/s |
|
Trimming speed |
0 – 24 mm/s |
|
Electricity |
380V, 50hz , 3ph |
|
Total Power |
6.5Kw / 8.7hp |
|
