CNC CENTER MACHINE - SCM
| CNC CENTER MACHINE - SCM | |
|---|---|
|
|
|
|
Brand |
SCM |
|
Industry |
|
|
Model |
PRATIX S18 A |
|
Year of manufacture |
2017 |
|
Weight |
3390 kg |
|
Air supply |
6.5 – 7.5 bar |
|
Suction flow rate |
30 m/sec |
|
Total power |
~ 48.25 hp |
|
Machine dimensions |
5700*3090*2190 mm |
|
Working area (X) axis |
3686 mm |
|
Working area (Y) axis |
1855 mm |
|
Working area (Z) axis |
150 mm |
|
Description |
Elec: 400v, 3ph, 50hz Max speed X-Y axis: 35 m/min Boring head: – Vertical spindles: 12 (8X-4Y) – Horizontal spindles: 6 (4X-2Y) – Saw blade: 125 mm Spindle: – Motor power: 9.5kw – Max speed: 24000 rpm – ATC: 11 places |
|
Documents |
|
