Edge Banding Machine - SCM

Edge Banding Machine - SCM
Brand
SCM
Industry
Italy
Model
Stefani Solution MD (MT-ER2)
Weight
2604 kg
Year
2016
Elec
400v, 50hz, 3ph
Track feed speed
10-25 m/min
Panel thickness
8 – 60 mm
Thickness of edges
0.4 – 15 mm
Distance between two panels
700 mm
Air pressure
6 bar
Description
Stages :-

– Glue Tank Compensatory (PUR – EVA)

– Pre-milling unit

– End cutting unit

– Line trimming unit

– Tillable trimming unit

– Rounding unit

– Edge scraper unit

– Glue scraping unit

– Brushing unit

– Heaters
