Beam Saw Machine – EXCITECH – EL Watania Company

Beam Saw Machine - EXCITECH

Brand	EXCITECH
Industry	China
Model	EP380
Dimensions	6000 × 6600 × 1750 mm
Weight	7000 KG
Cutting length	3800 mm
Max cutting height	110 mm
Total power	31 kW
Main saw power	18.5 kW
Grooving saw motor	2.2 kW
Saw carriage motor drive	2 kW
Main saw diameter	400 – 450 mm
Description	– Main saw shaft dia : 75 mm – Main saw speed : 3910 m/min – Groove saw diameter : 200 mm – Scoring saw shaft dia : 50 mm – Groove saw speed : 5860 m/min – Saw carriage cutting speed : 0 – 120 m/min – Automatic feed speed : 0 – 120 m/min – Number of clamps : 10 pcs – Optimization program : EXCITECH – QR code printer : Available – Air pressure : 6 – 8 bar
Documents	Download Machine PDF
