SIGMA XA-97M
SIGMA XA-97M - Image 2
SIGMA XA-97M - Image 3
SIGMA XA-97M - Image 4

SIGMA XA-97M

  • Brand: SIGMA
  • Model: XA-97M
  • Industry: China
  • Condition: New
  • Dimensions: 8890*1140*1850 mm
  • Brand: SIGMA
  • Model: XA-97M
  • Industry: China
  • Condition: New
  • Dimensions: 8890*1140*1850 mm
  • Weight: 3200 kg
  • Total power: 47.1 kw / 64 hp
  • Working pressure : 0.6 -0.8 Mpa
  • Dust collection outlet: Ø 100 mm*6
  • Panel thickness : 18-22 mm
  • Panel width: 150 mm
  • Edge band thickness: 300 mm
  • Voltage: 380v, 3ph, 50hz
  • Feeding speed: 6-8 m/min
  • Control screen : 15″ touch screen
  • Chain motor power : 4 kw
  • Pre-milling motor power: 2.2kw * 2
  • Profile forming: 4 kw
  • Fine profile forming : 6 kw
  • Heating lamp
